LE-TP
Topo Glass
Product Details
Product Item: On-line LOW E Glass
3.2mm 4mm 5mm 6mm 8mm 10mm 12mm On-line Low-E Glass
On-line Low-E Coated Glass; Low Emissivity Low E Glass; Energy Efficient Low-e Glass
Production Features:
◎Independent research and development technologies
—Self-developed advanced technology, production costs are relatively low and products have reached international advanced level
◎ High quality float glass
—The float glass production line integrates the production technology of PPG and is equipped with the most advanced production equipment and control system which can provide high-quality original float glass for the production of high-quality online LOW-E
◎Long-term storage and convenient logistics
—Equivalent to the storage, packaging and transportation of the original glass, it can be exposed to the air for a long time; the delivery cycle is short.
◎ Jumbo size specifications
—Online LOW-E glass is coated on the float production line and the coating process is continuous; its width is not limited by the specifications of the coating equipment. At present, our company can provide the maximum specifications of 3.3 meters by 6 meters; thickness is 3 ~ 12mm.
◎ Sufficient capacity
—The output of online LOW-E glass is not limited by the original glass and equipment. Our current production capacity can reach 6-12 million square meters per year.
—Stable chemical and mechanical performance for solid coat, high temperature resistance, corrosion resistance, anti-oxidation and long life
Key Specifications:
Product No. | LE-TP |
Product name | On-line Low-E Glass |
| Film Color | Clear/Gold |
| Substrate Color | Clear glass, Ultra Clear Glass, Tinted glass |
| Thickness | 3.2mm, 4mm, 5mm, 6mm, 8mm, 10mm, 12mm |
| Size | 2440mmx3300mm / 2440mmx3660mm / 2140mmx3300mm / 2140mmx3660mm / 1830mmx2440mm/ 1650mmx2140mm / 2140mmx1830mm / 1650mmx2440mm etc. |
| Customized | Customized |
| Structure | Solid |
| Technics | On-line Coated Glass |
| Transparency | Transparent |
| Packing | Safety Plywooden Packages |
MOQ | 20ft |
| Loading Port | Nansha Port / Huangpu Port / Yantian Port / Shekou Port |
| Delivery Time | Within 15 working days |
Application |
Architectural Field: Civil residence, schools, hospitals, office buildings, glass roof, etc. Traffic Locomotive Field: High speed train, subway and other rail train |
Online and Offline Low E Glass
| Contrastive Term | Online Low E Glass | Offline Low E Glass |
Process | By Chemical Vapor Deposition technique, coated on end of float line’s forming area | By physical magnetron sputtering technique, coated on annealed float glass |
Coating Material | SnO2 | Silver and multi layer metal oxides |
Machinability | Monolithic using avaliable, easy fabrication | Need to be used in IGU, coating edge deletion is necessary |
Emissivity | 0.15~0.25 | 0.02~0.15 Lower emissivity and more energy saving |
Optical properties | Visible light transmission 75% | Visible light transmittance monolithic >89%, hollow up to above82%; UV transmittance is only 52% (clear glass 71) |
Appearance | Higher haze, normal visual quality | Better visual quality, high grade feeling |
Application trends | Affected by the trend of energy conservation, Market interest reduction | More and more used, market share gradually increasing |
