Switchable Magic Electric Smart Laminated Privacy Glass

Availability:
Quantity:
  • UCEF-TP

  • Topo Glass

Product Details

Product Item: Switchable Electric Privacy Glass

Switchable Magic Electric Smart Laminated Privacy Glass

4mm+4mm, 5mm+5mm, 6mm+6mm, 8mm+8mm, 10mm+10mm, 12mm+12mm Electric Privacy Glass


The Special Functions of Ultra Clear Electric Film:

1.Using Ultra Clear Electric Film as electric curtain, we can control privacy easily;

2.UCEF smart film can block 99% UV, more than 70% IR, so it can decrease temperature and save energy as a result;

3.We can also use UCEF as projection display screen;

4.UCEF smart film can realize more functions when used together with intelligent control system.


Key Specifications:

 Product No.

 UCEF-TP

 Product name

 Privacy Glass / Switchable Glass / Electric Glass
 Thickness

 4mm+4mm, 5mm+5mm, 6mm+6mm, 8mm+8mm, 10mm+10mm, 12mm+12mm

 Size
 1800mm x 12000mm etc.

 Customized

 Customized

 Structure

 Solid

 UV Block

 More than 98%

 Original
 China

 Transparency

 Transparent & Opaque

 Packing

 Safety Wooden Packages

 MOQ

 20ft

 Loading Port

 Nansha Port / Huangpu Port

 Delivery Time

 Within 15 working days

 Usage

 Window, Wall, Door, Building, Railing


Product Show:

Switchable Smart Window Film for Office

Privacy Glass

Entranceway Privacy Glass Panels for Home Decor

Privacy Glass

Product Parameters:

Item Mode Parameter
Optical
Transmission(Parallelism) ON 78%(1%)
OFF <1%
Haze ON <7%
OFF >90%
View Angle ON about 150º
IR blocking ON >30%
OFF >90%
UV blocking ON >90%
OFF >99%
SHGC ON 0.78
OFF 0.06
Electrical Power transformer ON 60VAC
Response time OFF→ON 20ms
ON→OFF 10ms
Power consumption ON <5w/m2
Dimension Thickness N/A 0.37(0.02)
Surroundings Operating Temperature OFF→ON -40ºCto70ºC
Storage Temperature ON→OFF -50ºCto100ºC
Service Life Service Life(indoor) OFF→ON 10 years

Smart Privacy Glass, Smart Curtain Wall

Using Ultra Clear Electric Film on Glass Curtain Wall or glass windows as window curtain, it;s heat proof effect is as good as insulating paper or insulating glass. UCEF is used together with intelligent electric control equipment, controlling us clearance by light or heat. When temperature outside is too high. UCEF clearance with decrease accordingly, Less light and heat comes in as a result. And this kind of glass building is energy efficient.
